Description
Bently Nevada 330707-00-24-90-01-05 Proximity Sensor
Precision USA-made probe with 9-meter triaxial cable for industrial monitoring. Ships globally with full certification.
Product Identity
Brand: Bently Nevada
Type: 3300 XL 11mm Probe
Full Code: 330707-00-24-90-01-05
Configuration Breakdown:
- Base: 330707 (5/8-18 UNF thread)
- Unthreaded: 00 = 0 inch
- Case: 24 = 2.4 inch
- Cable: 90 = 9.0 meters
- Connector: 01 = ClickLoc with protector
- Certification: 05 = Multiple approvals
Technical Specifications
- Cable type: 75Ω triaxial FEP
- Probe resistance: 8.5Ω ±1.1Ω
- Temp range: -51°C to +177°C
- Min bend radius: 25.4mm
- Thread engagement: 0.938 inch max
- Torque max: 45.2 N•m (400 in•lb)
- Seal material: Viton O-ring
- Weight: 0.17 kg
- Tip material: PPS plastic
- Case material: 304 stainless steel
Installation Notes
- Use finger-tight connection (max 0.565 N•m)
- Maintain minimum 25.4mm cable bend
- Avoid temperatures below -34°C for seal life
- Max thread engagement: 0.938 inch
What You Receive
- New 3300 XL proximity probe
- Original factory packaging
- 12-month warranty documentation
Expert Questions
Q: Minimum temperature before seal damage?
A: Avoid below -34°C (-30°F)
Q: Cable insulation material?
A: FEP (fluoroethylene propylene)
Q: Thread type and size?
A: 5/8-18 UNF standard
Q: Triaxial cable benefits?
A: Better noise protection in harsh areas
Q: Pressure testing before shipment?
A: Not standard – contact for custom tests
