Bently Nevada 330903 NSv Compact M8 Probe
Precision vibration sensor for tight spaces. M8x1 threading, 1.0m cable, and miniature ClickLoc connector. Ideal for small machinery monitoring.
PRODUCT IDENTIFICATION
- Complete Part Number: 330903-00-02-10-02-05
- Configuration Details:
- Base: 330903 (M8x1 thread)
- Unthreaded: 00 = 0 mm
- Case: 02 = 20 mm
- Cable: 10 = 1.0 meter
- Connector: 02 = ClickLoc
- Certification: 05 = Multiple Approvals
TECHNICAL SPECIFICATIONS
| Electrical | Resistance: 4.2Ω ±0.5 Scale Factor: 7.87 V/mm Frequency: 0-10 kHz |
| Mechanical | Case: AISI304 SST Tip: PPS Plastic Cable: 75Ω FEP Coaxial |
| Performance | Linear Range: 1.5mm Min Target: 8.9mm Bend Radius: 25.4mm |
OPERATING PARAMETERS
- Temperature: -52°C to +177°C
- Max Torque: 7.3 N•m (65 in•lb)
- Safe Torque: 5.1 N•m (45 in•lb)
- Thread Limit: 12 mm engagement
- Seals pressure differences with Viton O-ring
INSTALLATION GUIDE
- Confirm M8x1 thread compatibility
- Apply torque gradually – max 7.3 N•m
- Set gap to 1.0mm (40 mils)
- Connect ClickLoc firmly
COMPATIBILITY
Works with all 3300 XL NSv monitoring systems. Backward compatible with 3300 RAM probes.
PACKAGE CONTENTS
- Probe assembly with connector
- Factory documentation
- 12-month warranty
SHIPPING
Ships worldwide via FedEx, UPS, DHL. Tracking provided.
TECHNICAL FAQ
Q: Minimum target size?
A: Works with 8.9mm targets but best on 13mm+
Q: Field wiring length limit?
A: Max 305m (1000ft) between probe and monitor
Q: Chemical resistance?
A: Superior to older RAM probes – good for compressors
Q: Scale factor accuracy?
A: 7.87 V/mm with ±20% tolerance
Q: Cable bend radius?
A: Minimum 25.4mm (1.0in) at all times
