Description
Bentley Nevada 3300 NSv Precision Probe
M8x1 threaded industrial sensor for vibration monitoring. New in factory packaging with full warranty.
PRODUCT SUFFIX DETAILS
- Base Model: 330903 (M8x1 thread, no armor)
- Unthreaded Length: 00 = 0 mm
- Case Length: 03 = 30 mm
- Cable Length: 10 = 1.0 meter
- Connector: 01 = Mini ClickLoc with protector
- Approvals: 05 = Multiple
CORE SPECIFICATIONS
- Linear Range: 1.5 mm (60 mils)
- Recommended Gap: 1.0 mm (40 mils)
- Scale Factor: 7.87 V/mm ±20%
- Accuracy: ±0.06 mm (±2.3 mils)
- Frequency Response: 0-10 kHz
MATERIALS & CONSTRUCTION
- Case: AISI 304 stainless steel
- Tip: Chemical-resistant PPS plastic
- Cable: 75Ω coaxial with FEP insulation
PERFORMANCE DATA
- Probe Resistance: 4.2Ω ±0.5Ω
- Max Torque: 7.3 N•m
- Safe Torque: 5.1 N•m
- Thread Engagement: Max 12 mm
- Min Target Size: 8.9 mm diameter
ENVIRONMENTAL RATING
- Operating Temp: -52°C to +177°C
- Bend Radius: 25.4 mm minimum
- Seal: Viton O-ring (differential pressure)
COMPATIBILITY
Works with all Bentley Nevada 3300 NSv systems. Backward compatible with 3300 RAM probes.
INSTALLATION GUIDE
- Set gap at 1.0 mm (40 mils)
- Apply torque ≤5.1 N•m
- Max field wiring: 305 meters
PACKAGE CONTENTS
- 3300 NSv Probe (1m cable)
- ClickLoc connector with protector
- Factory packaging
Warranty: 12 months manufacturer coverage
SHIPPING
FedEx | UPS | DHL – Worldwide delivery with tracking
TECHNICAL FAQ
Q: Minimum target size?
A: 8.9 mm diameter (13mm recommended)
Q: Cable length options?
A: 0.5m, 1m (this model), 5m or 7m
Q: Difference from 3300 RAM probes?
A: Better chemical resistance and side-view characteristics
Q: Pressure testing available?
A: Not standard – contact for custom solutions
Q: Field wiring requirements?
A: Use shielded triad cable (0.2-1.5mm²)
