330903-00-02-50-11-05 Bently Nevada 3300 NSv Proximity Probe

Description

Bently Nevada 3300 NSv Probe: Precision Vibration Sensing

Complete Product Details

• Part Number: 330903-00-02-50-11-05
• Suffix Breakdown:
  • -00- : 00 mm unthreaded length
  • -02- : 20 mm case length
  • -50 : 5.0 meter cable
  • -11 : ClickLoc connector with protector
  • -05 : Multiple agency approvals
• Warranty: 12 months factory coverage
• Shipping: FedEx, UPS, DHL express

Critical Performance Specs

• Linear Detection: 0.25-1.75mm range
• Response Speed: 0-10,000 Hz
• Cable Capacitance: 69.9 pF/m
• Center Conductor Resistance: 0.220 Ω/m
• Shield Resistance: 0.066 Ω/m

Construction Details

• Probe Tip: PPS plastic
• Housing: 304 stainless steel
• Seal: Viton O-ring
• Cable Type: FluidLoc FEP insulation
• Connector: Protected ClickLoc

Installation Guide

• Optimal Distance: 1.0mm from target
• Max Bend: 25.4mm radius
• Torque Limit: 0.56 N•m
• Thread Engagement: 12mm min
• Field Wiring: Max 305m length

Technical Questions

Q: What cable protection is included?
A: Connector protector for harsh environments

Q: FluidLoc vs standard cable?
A: Better chemical resistance in wet areas

Q: Minimum shaft size?
A: Works on shafts from 8.9mm diameter

Q: Pressure testing available?
A: Custom testing upon request
