Bently Nevada 3300 NSv Proximity Probe: Precision Industrial Sensing
Product Overview
Brand new 330903-00-02-70-11-00 proximity probe engineered for critical machinery monitoring. This M8X1 threaded sensor features 7.0-meter FluidLoc cable and miniature ClickLoc connector. Designed for chemical resistance and reliability in harsh industrial environments. Ships in original factory packaging with 12-month warranty.
Key Specifications
- Brand: Bently Nevada
- Full Model: 330903-00-02-70-11-00
- Measuring Range: 1.5mm (60 mils)
- Sensitivity: 7.87 V/mm ±20%
- Accuracy: ±0.06mm deviation
- Temp Range: -52°C to +177°C
- Output: -1 to -13 Vdc linear signal
- Cable: 7m FEP coaxial with ClickLoc
Advanced Features
- Superior side-view characteristics vs older probes
- Chemical-resistant PPS tip & stainless steel body
- Fully compatible with 3300 RAM probe systems
- Viton O-ring pressure sealing
- 5.9Ω ±0.9 probe resistance
Installation Guide
- Recommended gap: 1.0mm (40 mils)
- Max torque: 0.56 N•m (5 in•lb)
- Min target diameter: 13mm (0.5″)
- Min bend radius: 25.4mm (1.0″)
- Max wiring: 305m (1000 ft) shielded triad
Compatibility
Electrically and mechanically interchangeable with legacy 3300 RAM probes. Ideal for upgrading existing monitoring systems while gaining enhanced chemical resistance.
Certifications & Packaging
- Agency approvals: Not required (option 00)
- Factory sealed with connector protector
- 12-month warranty
Global Shipping
Available via FedEx, UPS, DHL with real-time tracking. International shipping options.
Frequently Asked Questions
Q: Is armor included?
A: No, this model (-11- option) has no armor.
Q: Pressure rating?
A: Not pressure-tested by default; contact for custom testing.
Q: Compatible with 190 series?
A: Yes, with superior side-view performance.
Q: Warranty terms?
A: 12 months from shipment date against defects.
