Description
Bently Nevada 3300 NSv Standard Cable Proximity Probe
Product Features
New original 330903-00-03-05-02-05 with 30mm case and standard cable. M8X1 thread design. Includes 12-month warranty in factory packaging.
Model Suffix Configuration
- 330903Base model-0000 mm unthreaded length-0330 mm case length-050.5 meter cable-02Standard cable with ClickLoc-05Multiple agency approvals
Technical Specifications
- Electrical Characteristics:
- Output signal: -1 to -13 Vdc
- Impedance: 75 Ω coaxial
- Capacitance: 69.9 pF/m typical
- Physical Properties:
- Cable insulation: FEP fluoropolymer
- Thread specification: M8x1 metric
- Max thread engagement: 12 mm
- Environmental Limits:
- Temp range: -52°C to +177°C
- Humidity: 0-100% non-condensing
- Seal material: Viton O-ring
Performance Metrics
- Accuracy: ±0.06 mm deviation from linearity
- Repeatability: ±0.02 mm typical
- Response Time: < 50 μs
Installation Guide
- Mounting torque: 5.1 N•m (45 in•lb) recommended
- Gap calibration: 1.0 mm optimal setting
- Wiring distance: 305m max with shielded cable
- Target material: Ferromagnetic steels recommended
Compatible Models Comparison
| Model | Case Length | Cable Type | Key Feature |
|---|---|---|---|
| 330903-00-04-05-12-00 | 40mm | Armored | Mechanical protection |
| 330903-00-02-05-12-00 | 20mm | Armored | Compact installation |
| This Model: 330903-00-03-05-02-05 | 30mm | Standard | Cost-effective solution |
Shipping & Packaging
- Factory-sealed anti-static packaging
- Connector protector included
- Global shipping: FedEx | UPS | DHL
- Express delivery options available
