Bently Nevada 3300 NSv Proximity Probe: Precision Industrial Sensing
Product Description
New & original Bently Nevada 330903-00-05-50-02-05 proximity probe with factory sealing. Features enhanced chemical resistance for harsh environments like process compressors. Fully compatible with legacy 3300 RAM systems. Includes 12-month warranty.
Technical Specifications
- Brand: Bently Nevada
- Full Model: 330903-00-05-50-02-05
- Range: 1.5 mm (60 mils)
- Accuracy: ±0.06 mm deviation
- Output Signal: -1 to -13 Vdc linear output
- Scale Factor: 7.87 V/mm (±12.5%)
- Temp Range: -52°C to +177°C
- Cable: 5.0 meters with ClickLoc connector
- Thread: M8X1 (12mm engagement)
- Material: Stainless steel case, PPS tip
Installation Guide
- Gap Setting: 1.0 mm (40 mils) optimal
- Torque: 5.1 N•m max (finger tight + ¼ turn)
- Min Target Size: 13 mm diameter
- Bend Radius: >25.4 mm
- Wiring: Use shielded triad cable (max 305m)
Compatibility & Certifications
Direct replacement for 3300 RAM probes. Carries multiple international agency approvals (option 05). Superior side-view performance vs. 3000-series probes.
Package & Warranty
- Factory-sealed new unit
- 12-month manufacturer warranty
- Shipping: FedEx/UPS/DHL worldwide
FAQ
Q: Is this compatible with 3300 RAM systems?
A: Yes – fully interchangeable
Q: Minimum target size?
A: 8.9mm absolute, 13mm recommended
Q: Pressure rating?
A: Viton O-ring seal (contact for pressure testing)
Download the full specification sheet for installation diagrams and performance graphs! 3300 XL NSv Proximity Transducer System Datasheet
