Description
Product Overview
Bently Nevada 3300 NSv Probe (Part 330905-00-08-10-01-05) is a new, factory-sealed sensor with a 1-year warranty. Designed for harsh industrial use, it offers better chemical resistance than older models and works well in compressors. Measures vibration with a linear range of 0.25–1.75 mm.
Key Features
- Size & Thread: M10X1 thread | Case length: 80 mm | Cable: 1.0 m (39 in).
- Connector: ClickLoc connector with protector | Standard cable | Shield resistance: 0.066 Ω/m.
- Certifications: Meets -05 safety standards for industrial use.
- Durability: Stainless steel case | Works in -52°C to +177°C.
Tech Specs
- Resistance: 4.2 ± 0.5 Ω (probe) | Capacitance: 69.9 pF/m.
- Output Sensitivity: 7.87 V/mm (±12.5%) | Accuracy: ±0.06 mm.
- Signal Range: Works up to 10 kHz with cables up to 305 m.
- Installation: Max torque: 0.56 N•m | Min bend: 25.4 mm.
Usage Tips
- Compatibility: Works with older 3300 RAM probes and cables.
- Target Size: Min 8.9 mm | Use 13 mm+ for best accuracy.
- Pressure Seal: Viton O-ring
Order & Support
Part: 330905-00-08-10-01-05
Warranty: 12 months
Contact: Email sales@ubestplc.com
