3500/05-01-02-00-00-00 Bently Nevada 3500 Series System Rack Solution

Description

Basic Product Identity

• Brand
  • Bently Nevada
• Product Name
  • 3500/05 System Rack
• Part Number
  • 3500/05-01-02-00-00-00
• Origin
  • Made in U.S.A

Model Code Structure

• 3500/05
  • 3500 monitoring system rack platform
• -01
  • 19 inch rack format
  • 14 module slots available
• -02
  • Rack mount style
  • Fits full-size 19 inch EIA cabinets
• -00
  • No special agency approval
• -00
  • No optional expansion defined
• -00
  • No European compliance option

Mechanical Layout

• Rack dimensions
  • Width 482.60 mm
  • Height 349.25 mm
  • Depth 265.94 mm
• Standard 19 inch cabinet fit.
• Front access module insertion.

Capacity and Structure

• Total slots
  • 14 usable module positions
• Supports monitoring and I/O cards.
• Backplane pre-wired for signal routing.
• Designed for continuous duty systems.

Electrical and System Data

• Compatible with 3500 power supplies.
• Backplane voltage distribution
  • Regulated rack power paths
• Grounded chassis design.
• Low resistance frame bonding.

Environmental Suitability

• Designed for industrial control rooms.
• Stable frame under vibration.
• Long service life in fixed installations.

Physical Weight

• Net weight
  • 6.5 kg

Main Product Benefits

• Central base for 3500 system.
• Easy future expansion.
• Strong metal construction.
• Clean cable routing.
• Industry proven rack design.

Warranty and Shipping

• 12 months warranty included.
• Tested before shipment.
• Delivery by FedEx, UPS, or DHL.

FAQ

• Is this rack suitable for new systems?
  • Yes. It is ideal for fresh 3500 installations.
• How many monitoring cards can be installed?
  • Up to fourteen modules can be used.
• What should be checked before ordering?
  • Confirm cabinet depth and power supply type.
• Can this rack be expanded later?
  • Yes. Spare slots allow easy upgrades.
• Is it compatible with older 3500 cards?
  • Yes. It supports standard 3500 modules.
