Product Description
The Bently Nevada 3500/92 Communication Gateway (Model: 3500/92-01-01-00) enables seamless integration of 3500 series monitoring systems with process control networks. Supporting Ethernet TCP/IP, RS232/RS422/RS485, and proprietary protocols, it provides real-time access to rack data, alarms, and statuses. Features include a Configurable Modbus Register Utility and compatibility with Bently Nevada configuration software.
Technical Data
- Brand: Bently Nevada
- Model: 3500/92-01-01-00
- Suffix Breakdown:
- I/O Module: 01 (Modbus RS232/RS422)
- Memory: 01 (Low Memory)
- Agency Approval: 00 (None)
- Power Consumption: 5.0W (RS232/RS422) / 5.6W (RS485)
- Data Types: Measured values, alarms, timestamps
- Update Rate: ≤1 second (rack-wide)
- Protocols: Modbus RTU/TCP, BNC Host Protocol
- Ethernet: 10Mbps (IEEE802.3), RJ-45 port
- Operating Temp: -30°C to +65°C (-22°F to +149°F)
- Dimensions (Main): 241×24.4×242 mm (9.50″x0.96″x9.52″)
- Weight: 0.82 kg (1.8 lb)
Installation Guide
Requires 1 front slot + 1 rear slot in 3500 series racks. Ensure power supply meets 24 VDC ±10% specifications. Use shielded Ethernet/RS485 cables for noise immunity.
Why Choose This Gateway?
- Dual-protocol flexibility (Modbus + BNC Host)
- Sub-second data updates for real-time monitoring
- Rugged design for -30°C to +65°C environments
Recommended Accessories
- 3500/15 Power Supply Module
- 3500 Rack Enclosure
- BNC Configuration Software
