Description
Siemens 6SE7018-0TA51-Z Power Inverter – High-Efficiency 8A Drive
Industrial-Grade DC-AC Conversion
The Siemens 6SE7018-0TA51-Z transforms 510-650V DC to precise AC power. This SIMOVERT MASTERDRIVES unit delivers 8A output with 0-400Hz frequency control for motor applications.
Technical Specifications
- Model: 6SE7018-0TA51-Z
- DC Input: 510-650V wide range
- AC Output: 0-480V, 8A
- Frequency: 0-400Hz adjustable
- Dimensions: 356 × 102 × 483 mm
- Weight: 9.1 kg
- Efficiency: 96% typical
- Cooling: Forced air with fan
- Response: <8ms speed change
- Protection: Overcurrent/voltage safeguards
Key Features
- Wide input tolerance for unstable power
- Precision frequency control
- Robust industrial construction
- Compact space-saving profile
Service & Support
- Global express shipping: FedEx, UPS, DHL
- 12-month performance warranty
- Technical support available
Expert Answers
- What’s the overload capacity?
150% for 60 seconds, 180% for 10 seconds. - Does it include I/O terminals?
Yes, 4 digital inputs, 2 analog outputs. - What clearance is needed for cooling?
50mm top/bottom, 30mm sides minimum. - Is parameter backup available?
Yes, stores settings during power loss. - What’s the THD at full load?
Under 4% total harmonic distortion.
