Product Description
The Bently Nevada 3300 XL 8 mm Proximity Probe (Model: 330104-01-08-50-01-00) is engineered for precision vibration and position monitoring in industrial applications. Featuring a 5.0-meter armored cable and a PPS probe tip, it delivers reliable performance in extreme conditions. The probe includes a Viton® O-ring for pressure sealing and a ClickLoc connector with protector for enhanced durability.
Technical Data
| Brand | Bently Nevada |
|---|---|
| Model | 3300 XL 8 mm Proximity Probe |
| Product No. | 330104-01-08-50-01-00 |
| Suffix Details | 01=10mm Unthreaded Length, 08=80mm Case Length, 50=5.0m Cable, 01=ClickLoc Protector, 00=No Agency Approval |
| Range | Calibrated for 1.27 mm (50 mils) gap with AISI 4140 steel target |
| Accuracy | Optimized for systems using 5-meter Proximitor sensors only |
| Output Signal | -4 Vdc to -20 Vdc (50 Ω resistance) |
| Power Supply | -17.5 Vdc to -26 Vdc (12 mA max with non-incendive circuits) |
| Probe Resistance | 8.73 Ω ±0.50 @5.0m |
| Operating Temp | -55°C to +232°C (EPL Ga/Gc, T1 rating) |
| Pressure Rating | Sealed for differential pressure via Viton® O-ring |
Certifications
- ATEX/IECEx: AEx/Ex ia IIC T1-T5 Ga (Zone 0), AEx/Ex nA IIC T1-T5 Gc (Zone 2)
- Hazardous Area Compliance: Class I Div 2, Groups A-D; Class II/III
Package & Warranty
- 8 mm Proximity Probe with M10x1 Thread
- Installation Manual & Compliance Documents
12-month warranty against manufacturing defects.
Contact: sales@ubestplc.com
Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
