Description
Product Description
The Bently Nevada 3300 XL 8 mm Proximity Probe (Model: 330104-05-10-10-02-CN) is a high-precision sensor designed for industrial machinery monitoring. Featuring an 8 mm probe tip with PPS material and a stainless steel case, it ensures durability in harsh environments. The probe includes a Vitron® O-ring for pressure sealing and comes with a Miniature ClickLoc connector for secure connectivity.
Technical Data
| Brand | Bently Nevada |
|---|---|
| Model | 3300 XL 8 mm Proximity Probe |
| Product No. | 330104-05-10-10-02-CN |
| Suffix Details | 05=50mm Unthreaded Length, 10=100mm Case Length, 10=1.0m Cable, 02=ClickLoc Connector, CN=Country Approval |
| Range | Optimized for 1.27 mm (50 mils) gap |
| Accuracy | System accuracy with AISI 4140 steel target |
| Output Signal | -4 Vdc to -20 Vdc (50 Ω resistance) |
| Power Supply | -17.5 Vdc to -26 Vdc (12 mA max) |
| Probe Resistance | 7.59 Ω ±0.50 @1.0m |
| Operating Temp | -55°C to +232°C (T1 classification) |
Certifications
- ATEX/IECEx: AEx/Ex ia IIC T1-T5 Ga, AEx/Ex nA IIC T1-T5 Gc
- Hazardous Area Ratings: Class I Div 2, Zone 0/2
Package & Warranty
- 8 mm Proximity Probe with Armor
- Installation Documentation
- Compliance Certificates
- ClickLoc Connector & Standard Cable
12-month warranty from date of delivery.
Contact: sales@ubestplc.com
Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
