Description
900RTC-L025 Honeywell Remote Terminal Low Voltage Cable Assembly
900RTC-L025 is a low voltage remote terminal cable designed for the Honeywell HC900 controller system.
It simplifies wiring between the controller and field devices.
The integrated design reduces installation time and improves connection reliability.
A 2.5 meter cable length allows flexible cabinet installation.
Key Features
- Brand: Honeywell
- Model: 900RTC-L025
- Cable length: 2.5 meters
- Designed for HC900 controller connection
- Integrated wiring solution reduces installation work
- Supports low voltage signal applications
- Shield drain wire improves grounding reliability
- Permanent installation design for industrial cabinets
Technical Highlights
- Cable type: Low voltage signal cable
- Connectors designed for HC900 control platform
- Integrated shielding improves signal stability
- Built-in protection with 80 mA time lag fuse
- Fuse model: Wickmann 3740080041
- UL and CSA approved fuse protection
- Stable signal transmission for industrial control systems
Installation Requirements
- Remove key tabs from terminal blocks before installation
- This allows correct cable mating
- Connect shield drain wire to HC900 rack grounding bar
- Verify DIP switch configuration before startup
- Switches SW1 to SW8 define signal input type
- Supported types include voltage, millivolt, ohms, milliamp, and RTD
Expert Review
- Engineers value the 900RTC-L025 for easy installation.
- Pre-assembled cable reduces wiring errors.
- Shield grounding improves signal stability.
- Fuse protection helps protect field circuits.
- Ideal for reliable industrial control systems.
Manager’s Insight
- This cable reduces installation labor time.
- Preconfigured connectors lower wiring risk.
- Standardized design improves maintenance efficiency.
- Reliable signal transmission improves control accuracy.
Suitable Equipment
- Honeywell HC900 process controllers
- Industrial automation control panels
- Temperature and process control systems
- Factory process monitoring systems
- Industrial instrumentation networks
Typical Application Scenarios
- Process automation plants
- Industrial furnace control systems
- Chemical production lines
- Power plant monitoring systems
- Industrial temperature measurement networks
Diagnostic Capability
- Shielded wiring reduces signal interference.
- Fuse protection helps detect abnormal current.
- Clear cable routing improves troubleshooting.
- Stable connection helps identify field device issues.
Shipping and Warranty
- Warranty period: 12 months
- Professional technical support available
- Orders ship within 24–48 hours
- International delivery via FedEx
- Express service available with UPS
- Global logistics supported by DHL
Professional FAQ
- Can the 900RTC-L025 cable be used for thermocouple signals?
- No. It is designed only for low voltage signal wiring.
- What controller does this cable support?
- It connects directly to Honeywell HC900 controllers.
- How should the shield drain wire be connected?
- Connect it to the grounding bar at the HC900 rack base.
- What should engineers check before installation?
- Verify DIP switch configuration for the correct signal type.
- How do buyers choose the correct cable assembly?
- Confirm controller model, signal type, and required cable length.
