Description
Bently Nevada 990-04-70-01-01: Precision Vibration Monitoring for Sensitive Machinery
???? Key Benefits for 990-04-70-01-01
???? Ultra-Precise 0-4 mils Range – Ideal for micro-vibration detection
????️ CSA Division 2 Certified – Safe for hazardous environments
???? 7m Extended Cable – 23ft reach for flexible installations
???? Technical Snapshots
- Model Code: 04=4 mils | 70=7m cable | 01=DIN rail | 01=CSA
- Accuracy: ±1.5% full scale
- Response: 5Hz-6kHz (±3dB)
- Fault Alert: <3.6mA output in 100μs
???? Package Includes
- Transmitter unit
- DIN rail clips
- 7m sensor cable
- 12-month warranty
⚙️ Installation Guide
- Mount on 35mm DIN rail
- Set probe gap to 0.5-1.75mm
- Max BNC cable: 3m
???? Model Comparison
990-05-50-01-01
5 mils range | 5m cable | Same mounting
990-08-50-01-01
8 mils range | Shorter 5m cable
???? Fast Shipping
FedEx | DHL | UPS – Global delivery in 3-5 days
❓ Quick Answers
Minimum target size?
9.5mm diameter (0.375″) required
COO available?
Free add-on document
