Description
The Bently Nevada 990-05-50-02-00 Vibration Transmitter is designed for continuous vibration monitoring using the 3300 NSv Proximity Probe for industrial machinery and rotating equipment. It provides reliable, real-time monitoring with a 4-20 mA output signal, enabling precise vibration measurements over a full-scale range. This transmitter is ideal for non-contacting proximity probes, offering easy integration into industrial control systems.
Technical Data
- Model Number: 990-05-50-02-00
- Full-scale Range: 05 = 0-5 mils pp (0-125 µm pp)
- System Length: 50 = 5.0 metres (16.4 feet)
- Mounting Option: 02 = Bulkhead screws
- Agency Approval: 00 = Not required
- Power Supply: Requires +12 to +35 Vdc input at the transmitter terminal
- Operating Temperature: -35°C to +85°C (-31°F to +185°F)
- Storage Temperature: -51°C to +100°C (-60°F to +212°F)
- Output Signal: 4 to 20 mAdc over specified full-scale range in 2-wire configuration
- Accuracy: ±1.5% over specified full-scale range
- Probe Gap: Between 0.5 and 1.75 mm (20 and 55 mils)
- Maximum Loop Resistance: 1,000 Ω including cable at 35 Vdc
- Prox Out Incremental Scale Factor: 7.87 mV/µm (200 mV/mil) ±6.5% typical
- Temperature Stability: Incremental scale factor remains within ±10% from 0°C to +70°C (+32°F to +158°F)
- Frequency Response: 5 Hz to 6,000 Hz +0, 3 dB
- Maximum Leadwire Length: 3 meters (10 feet)
- Non-hazardous Area Rating: Zone 2 or Div 2
- Weight: 0.43 kg (0.9 lb)
- Dimensions: 100 x 73.9 x 53.3 mm
