990-05-70-03-01 Bently Nevada | 990 Vibration Transmitter 12-35V DC

Description

Bently Nevada 990 Vibration Transmitter | Industrial-Grade Precision & Safety

???? Core Features

Engineered for 0-5 mils pp (0-125 μm pp) vibration monitoring, the 990-05-70-03-01 transmitter guarantees ±1.5% accuracy with CSA Div 2 certification. Built for reliability in hazardous zones.

???? Key Specifications

• Model: 990-05-70-03-01
• Range: 05 (0-5 mils pp / 0-125 μm pp)
• System Length: 70 (7.0m / 23ft)
• Mounting: 03 (DIN clips & screws)
• Certification: 01 (CSA Division 2)
• Output: 4-20 mA 2-wire
• Power: 12-35 Vdc
• Weight: 0.43 kg (0.9 lb)

⚡ Critical Performance

• ±1.5% Loop Accuracy (TEST input to 250Ω)
• Probe Gap: 0.5-1.75 mm (20-55 mils)
• Response: 5 Hz–6,000 Hz (±3 dB)
• Min Target Size: 9.5 mm (0.375″)
• Hazardous Rating: Zone 2/Div 2 (28V max)

???? What’s Included?

• Transmitter unit with DIN clips/screws
• Installation guide
• 12-month warranty
• COO (Certificate of Origin) available

???? Fast Global Shipping

FedEx | UPS | DHL | 3-5 business days

❓ Quick FAQs

Q: CSA certification details?
A: Approved for Division 2 hazardous areas.

Q: Signal during faults?
A: Drops to <3.6 mA within 100µs; recovers in 2-3s.

Q: Leadwire limits?
A: Max 3m (10ft) from BNC connector.
