990-05-70-03-CN – Bently Nevada 990 Vibration Transmitter 4-20 mA

Description

Bently Nevada 990 Vibration Transmitter | Precision Engineered for Global Compliance

???? Core Advantages

The 990-05-70-03-CN delivers ±1.5% accuracy across a 0-5 mils pp (0-125 μm pp) range. Certified for CN country-specific approvals, it’s ideal for Zone 2/Div 2 hazardous areas.

???? Technical Breakdown

• Model: 990-05-70-03-CN
• Range: 05 (0-5 mils pp)
• Cable Length: 70 (7.0m / 23ft)
• Mounting: 03 (DIN clips & screws)
• Compliance: CN Approvals
• Output: 4-20 mA (2-wire)
• Power: 12-35 Vdc
• Weight: 0.43 kg (0.9 lb)

⚙️ Performance Highlights

• ±1.5% loop accuracy at 250Ω resistance
• Probe Gap: 0.5-1.75 mm (20-55 mils)
• Response: 5 Hz–6,000 Hz (±3 dB)
• Min Target: 9.5 mm (0.375″) diameter
• Fault Response: <3.6 mA within 100µs

???? Package & Logistics

• Transmitter, DIN mounting kit, manual
• 12-month warranty against defects
• COO (Certificate of Origin) available
• Global Shipping: FedEx, UPS, DHL (3-5 days)

❓ Top Questions

Q: Hazardous area rating?
A: Zone 2/Div 2 compliant (28V max).

Q: Max cable length?
A: 3 meters (10ft) from BNC connector.

Q: Current limit?
A: 23 mA typical under 35 Vdc.
