AAI143-H53/K4A00 | Analog Input Module Yokogawa

Description

Yokogawa AAI143-H53/K4A00: Isolated HART Input Module

Product Description

Advanced 16-channel isolated module with HART protocol support. Features 1500V isolation and ±16µA accuracy. Designed for critical process measurement in harsh industrial environments.

Technical Specifications

• Brand: Yokogawa
• Model: Analog Input Module
• Full Suffix: AAI143-H53/K4A00
• Suffix Breakdown:
  • AAI143: Analog Input Module
  • H: HART Protocol
  • 5: No Explosion Protection
  • 3: ISA G3 + Temp (-20°C to 70°C)
  • /K4A00: KS Interface Adapter
• Channels: 16 isolated
• Input Signal: 4-20mA
• Accuracy: ±16µA
• Isolation: 1500V AC (input-system)
• Update Speed: 10ms
• Temperature: -20°C to 70°C
• Power: 24V DC
• Weight: 0.3kg

Installation Guide

• Use KS interface adapter for AEA4D terminal boards.
• Maintain 1500V isolation clearance.
• Set 2/4-wire mode per channel.

Compatibility

Works with Yokogawa FCS systems. Requires AEA4D terminal board. Supports HART-enabled transmitters.

Package Contents

• AAI143-H53 module
• KS interface adapter (ATK4A-00)
• Operation manual

Warranty & Shipping

12-month warranty. Ships via FedEx/UPS/DHL worldwide. Delivery in 3-5 days.

Real-World Applications

Chemical Processing: HART-enabled reactor temperature monitoring
Power Plants: Isolated 4-20mA reading for turbine sensors
Mining Operations: Vibration monitoring in -20°C environments

FAQ

Q: What does /K4A00 suffix mean?
A: Includes KS Interface Adapter for AEA4D terminal boards

Q: Maximum ambient temperature drift?
A: ±16µA per 10°C change

Q: Can it power transmitters?
A: Yes – provides 19-25.5V loop power (25mA limit)
