Description
Product Overview
- Brand: AAR Series
- Model: AAR181-S00
- Type: RTD Input Module
- Core Feature: 12 isolated RTD channels
- This module ensures stable temperature measurement.
- Each channel supports independent setup.
- It fits harsh industrial environments.
- High isolation protects signal integrity.
- Accurate data supports process control.
Technical Specifications
- Model: AAR181-S00
- Brand: AAR Series
- Channels: 12 isolated inputs
- Input Signal: Pt100 RTD, 3-wire
- Standard: JIS C1604, IEC751
- Measurement Range: Industrial RTD range
- Accuracy: ±120 mΩ
- Resolution: High precision
- Linearity: Stable across range
- Sensitivity: Detects small changes
- Measurement Current: 1 mA
- Update Rate: 1 second
- Input Voltage: ±5 V
- Input Resistance: ≥2 MΩ
- Temperature Drift: ±120 mΩ per 10°C
- Wiring Resistance: ≤1000 Ω
- Compensation Accuracy: ±1°C
- Isolation: 1500 V AC
- Power Supply: 5 V DC
- Max Current: 450 mA
- Operating Temperature: -20 to 70°C
- Anti-interference: Strong noise immunity
- Dimensions: 130 × 107.5 × 32.8 mm
- Weight: 0.2 kg
- Terminal: Pressure clamp
Suffix Structure
- -S
- Standard version
- -5
- No explosion protection
- -E
- Explosion protection
- -0: Basic type
- -3: G3 coating, wide temperature
Optional Accessories
- /R8S00: RTD terminal block
- /R8S10: Terminal with surge protection
- /R8D00: Dual terminal block
- /R8D10: Dual with surge protection
- /CCC01: Connector cover
Installation Guide
- Install on compatible rack system.
- Use correct 3-wire RTD wiring.
- Secure wiring with clamp terminals.
- Avoid strong electromagnetic interference.
- Ensure proper grounding.
Commissioning and Maintenance
- Set each channel independently.
- Enable burn-out detection if needed.
- Check signals during startup.
- Maintenance is simple and fast.
- Module replacement is quick.
Compatibility
- Supports mainstream PLC and DCS systems.
- Works with Yokogawa Centum VP.
- Suitable for automation platforms.
Certification and Reliability
- Meets industrial standards.
- Explosion-proof option available.
- G3 coating for harsh environments.
Packing and Warranty
- 1 × AAR181-S00
- Optional accessories included
- User manual
- 12-month warranty
- Shipping: FedEx, UPS, DHL
Typical Applications
- Temperature monitoring systems
- Oil and gas industry
- Power plants
- Chemical processing
- Industrial automation
Diagnostics Capability
- Burn-out detection
- Wiring fault detection
- Signal drift monitoring
- Improves system safety
FAQ
- What sensor type is supported?
- Pt100 RTD with 3-wire connection.
- Can channels be configured separately?
- Yes, each channel supports independent setup.
- Is it resistant to noise?
- Yes, strong anti-interference design.
- How to choose explosion protection?
- Select -E suffix for hazardous areas.
- How to ensure accuracy?
- Use quality sensors and proper wiring.
- What to check before purchase?
- Confirm system compatibility and signal type.
