Essential System Connector: The ABB SC510 Carrier
This is the ABB SC510 submodule carrier. It is a key part of the AC460 control system. The module brings data into your system. It holds two personality modules. This lets you connect many devices. Use it with S800 I/O, S100 I/O, and more. It is new and ready to ship.
Core Features & Benefits
- Modular Design: One carrier supports two different I/O or communication modules.
- Saves Space: Compact size for high-density control cabinet installation.
- System Flexibility: Connects to S800 I/O, S100 I/O, and third-party devices via MVI.
- Reliable Performance: Built by ABB for stable operation in industrial settings.
- Easy Integration: Simplifies expansion and configuration of your AC460 system.
Detailed Product Specifications
- Brand: ABB
- Product ID: 3BSE003832R1
- Model: SC510 Submodule Carrier
- Series: AC460 System Component
- Type: Communication / Carrier Module
- Function: Carrier for two personality modules (no CPU).
- Physical Dimensions (L x W x H): 288 mm x 486 mm x 22.5 mm
- Net Weight: 0.67 kg
- Power Requirements (Typical):
- 5 Volts DC: 1.8 A
- 24 Volts DC: 0.54 A
- Cooling Load: 75 BTU/H (Typical)
- Operating Temperature: Standard industrial range (refer to manual).
- Storage Temperature: -40°C to +70°C
- Relative Humidity: 5-95% non-condensing
- Compliance: RoHS compliant (EU Directive 2011/65/EU)
- WEEE Category: 5 – Small Equipment
What’s in the Box & Support
- ABB SC510 Carrier Module (Part: 3BSE003832R1).
- New, original ABB product in factory packaging.
- Warranty: Full 12-month factory warranty.
- Global Shipping: We ship worldwide via FedEx, UPS, and DHL.
Typical Applications
- Expanding I/O capacity in AC460 control systems.
- Creating interfaces for TRIO controllers or other vendor devices.
- Building custom system configurations with mixed I/O types.
- Used in kits for specific system hardware setups.
Frequently Asked Questions (FAQ)
Installation & Setup
Does the SC510 module need a special power supply?
It uses standard system power from the AC460 base. Ensure your power design meets the 5V and 24V current needs listed.
Can I install any two personality modules?
Yes. You can mix different types, like one S800 I/O module and one MVI module, for maximum flexibility.
Compatibility & Use
Is the SC510 compatible with older ABB systems?
It is designed for the AC460 system. Always check your system manual for specific compatibility details.
How do I know which personality modules to order?
Choose modules based on your I/O needs (digital, analog) or communication needs (MVI). The SC510 is just the carrier.
Best Practices
What is a common oversight during installation?
Forgetting to account for the total cooling load. Add up the BTU/H for all modules in your cabinet for proper cooling.
