Allen-Bradley 1756-OF8IH ControlLogix HART Analog Output Module

Description

Allen-Bradley ControlLogix HART Analog Output Module

Upgrade your process control with the Allen-Bradley 1756-OF8IH. This advanced module combines 8 isolated analog outputs with HART communication. It offers high precision and smart device integration in one compact solution.

Technical Specifications

Brand: Allen-Bradley
Model: 1756-OF8IH
Series: ControlLogix
Type: HART Analog Output Module
Channels: 8 isolated differential outputs
Output Range: 0-20mA, 4-20mA
Resolution: 15 bits
Accuracy: ±0.15% at 4-20mA
HART Support: Version 5, 6, 7
Isolation: 250V output-to-backplane
Protection: ±24V overvoltage protection
Response Time: <100ms with HART, <23ms without
Load Capacity: 50-750Ω
Backplane Current: 400mA @ 24V DC
Operating Temp: 0 to 60°C
Calibration Interval: 12 months recommended

Package & Support

• One 1756-OF8IH analog output module
• 12-month performance warranty
• Worldwide shipping via FedEx, UPS, DHL

Resources & Documentation

• Installation guidelines
• Wiring diagrams
• Configuration examples
• Download complete technical manual here
