Allen-Bradley 1768-M04SE SERCOS Interface Module | 4-Axis Motion Control
The Allen-Bradley 1768-M04SE is a SERCOS interface module for CompactLogix systems. It integrates motion control and connects up to four Kinetix servo drives. This module works with 1768-L43 and 1768-L45 controllers for high-performance automation.
Technical Specifications
- Brand: Allen-Bradley by Rockwell Automation
- Model: 1768-M04SE
- Product Type: SERCOS Interface Module
- Supported Drives: Up to 4 Kinetix 2000, 6000, 7000, or Ultra 3000
- Power Dissipation: 5.04 W
- Backplane Current: 969 mA @ 5.2V DC
- Data Rate: 4 Mbps or 8 Mbps
- Cycle Time: As low as 0.5 ms
- Connector Type: F-SMA Fiber Optic
- Isolation Voltage: 30V Continuous
- Operating Temperature: -20°C to 85°C (Glass Fiber)
- Installation: DIN Rail or Panel Mount
- Dimensions: 132mm x 57mm x 105mm
- Weight: 0.2 kg
Compatible Cables
- Compatible plastic fiber cables include 2090-SCEPxx-0, 2090-SCVPxx-0, and 2090-SCNPxx-0.
- Glass fiber options such as 2090-SCVGxx-0 are also supported.
- All cables offer high flexibility and bend resistance.
Packaging & Shipping
- Package includes one 1768-M04SE module and installation documentation.
- We ship via FedEx, UPS, or DHL for fast and reliable delivery.
Frequently Asked Questions
- Q: How many drives can the 1768-M04SE control?
A: It supports up to four SERCOS-based Kinetix or Ultra 3000 drives. - Q: What controllers are compatible?
A: It works with 1768-L43 and 1768-L45 CompactLogix processors. - Q: What is the maximum cycle time?
A: Cycle time is 1 ms or lower, depending on data rate and drive count.
Comparison Products
Compare with other controllers like 1766-L32BWA or 1766-L32BWAA.
