Allen-Bradley 1769-L30ER: Advanced CompactLogix Programmable Controller
The 1769-L30ER from Allen-Bradley/Rockwell Automation delivers powerful control capabilities in a compact form factor. This versatile programmable automation controller features integrated communications and expandable I/O capacity.
Technical Specifications
- Brand: Allen-Bradley
- Model: 1769-L30ER
- Product Type: Programmable Automation Controller
- Memory Capacity: 1 MB user memory with 1 GB SD card included
- Communication Ports: Dual Ethernet/IP ports, 1 USB programming port
- Ethernet Speed: 10/100 Mbps auto-negotiating
- Network Topologies: Device Level Ring (DLR), Linear, Star
- Maximum Nodes: 16 Ethernet devices supported
- I/O Capacity: 8 Compact I/O modules across 3 expansion banks
- Programming Languages: Ladder Logic, Structured Text, Function Block, SFC
- Power Supply Distance: 4 modules maximum from power supply
- Operating Temperature: 0 to 60°C (32 to 140°F)
- Vibration Resistance: 5g at 10-500 Hz operating
- Certification: cULus Class I, Division 2 hazardous location
- Non-Volatile Memory: 1784-SD1 1GB card included, upgradeable to 2GB
- Battery: 1747-BA lithium battery for memory backup
- Mounting: DIN rail or panel mount with 50mm clearance
- Dimensions: Standard single-slot width
- Weight: 1.8 kg (4 pounds)
Package Contents
- 1769-L30ER Programmable Controller
- 1784-SD1 1GB secure digital memory card
- Installation documentation and user manual
- Required mounting hardware for secure installation
Frequently Asked Questions
- What is the maximum communication distance for Ethernet?
- 100 meters standard, extendable with switches or fiber converters
- Can I upgrade the non-volatile memory capacity?
- Yes, with optional 1784-SD2 2GB memory card
- What power supplies are compatible with this controller?
- 1769-PA2, PB2, PA4, and PB4 power supply modules
- Does this controller support redundant network configurations?
- Yes, it supports Device Level Ring for fault tolerance
- What shipping methods are available?
- We ship worldwide via FedEx, UPS, and DHL express services
Comparison With Similar Products
- For different controller options, consider the 1769-L30 CompactLogix processor
- The 1769-IQ32 offers high-density discrete input capability
Warranty: This product includes a 12-month warranty against manufacturing defects.
