Allen-Bradley 1769-PB2 CompactLogix I/O Power Supply
Power your CompactLogix system reliably with the Allen-Bradley 1769-PB2 DC power supply module. This robust unit is designed to energize up to 16 I/O modules, with 8 modules on each side, making it a central power hub for your control cabinet. It ensures stable operation for your entire system.
Key Features & Description
The 1769-PB2 is an essential component for any CompactLogix setup. It accepts a wide input voltage of 19.2-31.2V DC and delivers clean power to your modules. With outputs of 2.0A @ 5VDC and 0.8A @ 24VDC, it meets the demands of various sensors and actuators. Its open-style design requires installation in a protective enclosure, and it supports both panel and DIN rail mounting for easy integration. Need help? Support, Inquiry, Contact: +86 158 8020 0923
Technical Data
- Brand: Allen-Bradley / Rockwell Automation
- Model: 1769-PB2 (Series A/B)
- Input Voltage: 19.2 – 31.2 VDC (Nominal 24VDC)
- Output Current: 2.0 A @ 5VDC, 0.8 A @ 24VDC
- Power Dissipation: 7.5 W @ 60°C
- Max Modules Supported: 16 (8 per side)
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Wire Size: 14-22 AWG
- Fuse: 3.15A (Internal)
- Weight: Approx. 485 g (1.07 lb)
Installation Guide
Mount the 1769-PB2 in your CompactLogix rack or expansion bank. Use 14 AWG solid copper wire with 90°C rating for best results. Ensure the input power is within the 19.2-31.2V DC range. Remember, the entire assembly must be housed in a suitable industrial enclosure for safety.
Compatibility
This power supply is fully compatible with the CompactLogix 1769 series I/O modules. It is designed to work seamlessly within the Rockwell Automation ecosystem.
Packaging & Warranty
Each unit comes with the 1769-PB2 power supply module. We offer a 12-month warranty for your peace of mind. We ship globally via FedEx, UPS, and DHL for fast delivery.
