Allen-Bradley 1783-SFP1GLX Stratix Fiber Transceiver LX Module

Description

Product Overview

The 1783-SFP1GLX is a fiber SFP transceiver from Allen-Bradley.
It is designed for Stratix managed switches.
The module supports long-distance data transfer.
It ensures stable and secure Ethernet links.

Key Product Benefits

• Long fiber reach up to 10 kilometers.
• Industrial temperature range for extreme sites.
• Optical monitoring for early fault warning.
• Hot-pluggable design for fast replacement.
• High signal stability for critical networks.

Technical Specifications

• Brand: Allen-Bradley / Rockwell Automation
• Series: Stratix Managed Switches
• Model: 1783-SFP1GLX
• Product Type: Pluggable Fiber Transceiver
• Ethernet Standard: 1000BASE-LX/LH
• Fiber Type: Singlemode
• Maximum Distance: 10 km
• Wavelength: 1310 nm
• Connector Type: Dual LC
• Core Size: G.652 fiber
• Memory Capacity: 1 GB
• Digital Optical Monitoring: Supported
• Operating Temperature: -40 to 85 °C
• Wire Gauge: 18 to 20 AWG
• Typical Power Consumption: Less than 1.5 W
• Insertion Loss: Low-loss optical design
• Signal Speed: 1 Gbps

Reliability and Protection

• Stable optical output under load.
• Strong resistance to EMI noise.
• Designed for continuous operation.
• Supports fault prediction via DOM.

Installation Notes

• Insert module into SFP slot.
• Use clean LC fiber connectors.
• Confirm fiber polarity.
• Check link status after power-up.

System Compatibility

• Compatible with Stratix Ethernet switches.
• Works in EtherNet/IP networks.
• Supports industrial control systems.

Standards and Approvals

• Complies with ROSTECHNADZOR rules.
• Approved under KC certification.

Packing and Delivery

• 1 × 1783-SFP1GLX fiber transceiver
• Anti-static protective packing
• Industrial-grade shipping box

Warranty and Shipping

• Warranty period: 12 months
• Shipping methods: FedEx, UPS, DHL
• Fast global delivery available

Typical Applications

• Factory backbone networks
• Process automation systems
• Remote control cabinets
• Oil, gas, and power plants
• Industrial data centers

FAQ

• Can this SFP run continuously in hot areas?
• Yes. It supports up to 85 degrees Celsius.
• Is this module safe for long-distance links?
• Yes. Singlemode fiber supports stable 10 km transmission.
• Does optical monitoring improve maintenance?
• Yes. DOM helps detect signal loss early.
• How to choose between LX and SX modules?
• Choose LX for long distance. Choose SX for short runs.
• Is this module suitable for critical control data?
• Yes. It offers stable speed and low packet loss.
