Allen Bradley 22B-D012H204 Drive PowerFlex 40P

Description

Allen-Bradley PowerFlex 40 Drive – 22B-D012H204

Powerful 7.5 HP motor control with the 22B-D012H204 variable frequency drive. Perfect for industrial applications needing 12A output at 480V. Features compact design and advanced control options.

Key Features

• 7.5 HP (5.5 kW) power output
• 12A current capacity
• Works with 380-480V AC, 3-phase
• Compact plate drive design
• Built-in RS-485 communication
• Brake IGBT for quick stopping

Technical Specifications

• Model: 22B-D012H204
• Dimensions: 284 x 155 x 108 mm (11.18 x 6.1 x 4.25 in)
• Weight: 2.59 kg (5.7 lbs)
• Control Voltage: 24V sink/source
• Shock Resistance: 30g operating / 50g non-operating
• Control Methods: V/Hz & Sensorless Vector
• ESD Protection: Required during installation

FAQ

• What special handling is required? ESD precautions must be followed during installation.
• Can it handle low-speed applications? Yes, with sensorless vector control.
• What’s the control voltage requirement? 24V sink/source input.
• Does it include braking? Yes, with built-in brake IGBT.
• What’s the warranty period? 12 months full coverage.

Shipping & Support

• 12-month warranty
• Fast worldwide shipping via FedEx, UPS, or DHL
• Technical support available

Compare Models

• 22B-E019H204 – 19A, 600V model
• 22B-E019N104 – 19A, panel mount version
