Allen Bradley 22D-D1P4N104 Drive PowerFlex 40P

Description

Allen-Bradley 22D-D1P4N104 – Compact & Powerful VFD Drive

Key Specs – 22D-D1P4N104

• Input: 342-528V AC, 3-phase, 1.8A
• Output: 0-460V AC, 1.4A, 0.5HP
• Frequency: 0-500 Hz
• Mounting: Vertical panel (IP20)
• Temperature: 14°F to 122°F
• Controls: 7 digital inputs, 1 analog output

What Makes It Special

• Built-in RS485 communication
• Works with PID control
• Safe voltage discharge (wait 3 mins after power off)
• ESD protection for sensitive parts
• UL, CE, CSA certified

Installation Tips

• Use M4 screws (#8-32 size)
• Keep fan clean from dust
• Avoid wet or sunny locations
• Leave space around drive for cooling

Professional FAQs

• Q: Can the 22D-D1P4N104 work with single-phase motors?
  A: No, it’s designed for 3-phase motors only.
• Q: How do I reset fault codes?
  A: Use the keypad or power cycle the drive.
• Q: What’s the maximum cable length?
  A: Keep motor cables under 50 feet for best performance.
• Q: Can I add an external filter?
  A: Yes, for better EMC protection.
• Q: Is encoder feedback supported?
  A: Yes, for precise speed control.

Compare With Similar Models

• 22D-E1P7H204 (2HP, 600V model)
• 22D-E1P7N104 (1HP, 240V model)

What’s Included

• 22D-D1P4N104 VFD unit
• Installation guide
• Mounting screws

Warranty & Shipping

• 12-month product warranty
• Fast shipping via FedEx, UPS, DHL
