PowerFlex 4M Adjustable Frequency AC Drive – 22F-D4P2N113
Description
The Allen-Bradley 22F-D4P2N113 is a compact and efficient variable frequency drive (VFD) designed for industrial motor control. Part of the PowerFlex 4M series, this drive supports V/Hz control and is ideal for modulating motor speed in automation applications. It features a built-in keypad for easy configuration and an EMC filter for noise reduction. With RS485 communication (Modbus RTU), it integrates seamlessly into control systems.
Technical Data
- Brand: Allen-Bradley (Rockwell Automation)
- Model: PowerFlex 4M – 22F-D4P2N113 (Full Suffix)
- Input: 380-480V AC, 3-Phase, 3.5A
- Output: 0-460V AC, 3-Phase, 4.2A, 1.5 kW (2 HP)
- Frequency Range: 0-400 Hz
- Control Method: Volts/Hertz (V/Hz)
- Discrete Inputs: 5x 24V DC
- Analog Inputs: 2x (0-10V/4-20mA)
- Relay Outputs: 2x Form C
- Enclosure: IP20 (Open Frame)
- Communication: RS485 (Modbus RTU/DSI)
- Operating Temp: -40°F to 185°F (-40°C to 85°C)
- Mounting: Panel or DIN Rail
Installation & Compatibility
Designed for 3-phase motors, this drive is compatible with Allen-Bradley PLCs and supports Modbus RTU. Optional communication modules (DeviceNet, EtherNet/IP) are available. Install in IP20 enclosures or DIN rails. Download the manual for wiring diagrams: Click Here.
Package & Warranty
- Included: Drive unit, keypad, user manual.
- Shipping: FedEx, UPS, or DHL (express options available).
- 12-Month Warranty – Covers defects in materials/workmanship.
Note: Brake IGBT sold separately. Contact us for bulk discounts.
