Allen-Bradley 1769-L33ER: High-Performance CompactLogix Controller
The 1769-L33ER from Allen-Bradley/Rockwell Automation delivers advanced control capabilities with expanded memory and connectivity. This powerful programmable automation controller handles medium to complex automation applications with exceptional reliability.
Technical Specifications
- Brand: Allen-Bradley
- Model: 1769-L33ER
- Product Type: Programmable Automation Controller
- Memory Capacity: 2 MB user memory with 1 GB SD card included
- Communication Ports: Dual Ethernet/IP ports, 1 USB programming port
- EtherNet/IP Speed: 10/100 Mbps auto-negotiating
- I/O Capacity: 32 local I/O modules across 3 expansion banks
- Maximum Nodes: 32 Ethernet devices supported
- Multi-tasking: Supports 32 tasks with 100 programs per task
- Backplane Current: 560 mA at 5V DC, 500 mA maximum
- Power Dissipation: 4.5 Watts maximum
- Operating Temperature: 0 to 60°C (32 to 140°F)
- Storage Temperature: -40 to 85°C (-40 to 185°F)
- Humidity Range: 5-95% non-condensing
- Vibration Resistance: 5g at 10-500 Hz operating
- Shock Resistance: 20g (DIN rail), 30g (panel mount)
- Certifications: cULus, CE, C-Tick, CI compliance
- Battery: Internal energy storage (no battery required)
- Dimensions: Standard single-slot width
- Weight: 0.31 kg (0.68 lb)
Package Contents
- 1769-L33ER Programmable Controller
- 1784-SD1 1GB secure digital memory card
- Installation documentation and user manual
- Required mounting hardware for secure installation
Frequently Asked Questions
- What is the maximum number of I/O points supported? It supports up to 32 local I/O modules with extensive point capacity
- Does this controller require battery replacement? No, it uses internal energy storage without battery requirements
- What programming software is compatible? Studio 5000 Logix Designer for complete programming capability
- Can I expand the non-volatile memory capacity? Yes, with optional 1784-SD2 2GB memory card upgrade
- What shipping methods are available? We ship worldwide via FedEx, UPS, and DHL express services
Comparison With Similar Products
- For communication modules, consider the 1769-SM1 communication module
- The 1769-OF2 offers analog output capability for control applications
Warranty: This product includes a 12-month warranty against manufacturing defects.
