Description
Allen-Bradley 22D-B5P0N104 PowerFlex Drive – 1HP Motor Control Expert
Best for: The Allen-Bradley 22D-B5P0N104 delivers reliable speed control for 1HP motors in industrial applications like conveyors and spinning machines.
Complete Specifications
- Model: 22D-B5P0N104 (PowerFlex 40P Series)
- Power: 1 HP (0.75 kW) output
- Voltage: 240V AC (3-phase)
- Current: 5.0 Amps
- Efficiency: 97.5%
- Dimensions: 100 x 213 x 135.89 mm
- Weight: 1.8 kg (4 lbs)
- Control Methods: V/Hz, Sensorless Vector
- Protection: Ground fault, overload, 6kV transient
- Stop Modes: Coast, Ramp, DC-Brake
- Temperature Range: 0°C to 50°C (operating)
Technical FAQs
- What’s the maximum ambient temperature?
- 40°C for normal operation.
- Does it need external cooling?
- No, uses natural convection cooling.
- Can I use it with single-phase power?
- No, 3-phase power required.
- How many acceleration profiles are available?
- Four programmable settings.
- Is the display backlit?
- Yes, for easy reading in low light.
Package & Support
- 12-month product warranty
- Fast global shipping options
- Includes mounting hardware
Alternative Models
- 22B-E6P6F104 (Higher current 6.6A version)
- 22B-E6P6H204 (480V voltage model)
