Allen-Bradley 1769-SM1 Communication Module
Connect your drives easily. The Allen-Bradley 1769-SM1 links CompactLogix to PowerFlex drives. This 1769-SM1 module makes automation simple.
Main Features
- Drive Connection: Works with PowerFlex 7-Class drives
- Auto-Detect: Finds DPI or SCANport hosts automatically
- Easy Setup: No complex configuration needed
- Compact Size: Fits small control panels
Technical Specifications
- Brand: Allen-Bradley
- Model: 1769-SM1
- Product Line: CompactLogix
- Protocols: DPI, SCANport
- Data Rates: 125 kbps, 500 kbps
- Power Consumption: 280 mA @ 5V DC
- Operating Temperature: -10°C to 50°C
- Weight: 142 grams
- Dimensions: 118mm x 87mm x 35mm
- Cable Length: Up to 100 meters
- Mounting: DIN Rail or Panel
Installation
Mount the 1769-SM1 on DIN rail. Keep away from dust and chemicals. Use proper cables. Follow length limits.
Compatible Products
Works with MicroLogix 1500 and CompactLogix. Also check:
1769-BA Battery Module
1769-ECL End Cap
FAQ
- What drives does it work with? PowerFlex 7-Class and DPI devices.
- What is the maximum cable length? 100 meters at 125 kbps.
- Does it need special software? No, it auto-detects settings.
- What is the power requirement? 5V DC, 280 mA.
- Can it be used outdoors? No, keep in clean indoor areas.
