Description
Allen-Bradley PowerFlex 40 Drive – 22B-D2P3C104 (1HP)
Meet the rugged 22B-D2P3C104 drive – built tough for harsh environments. With IP66 protection, it handles dust and water spray. Perfect for outdoor or dirty locations.
Get the full story: Download Manual PDF
Top Features
- 1HP power (2.3A output)
- Super strong IP66/NEMA 4X case
- Works with 480V 3-phase power
- Easy keypad control with LCD
- Built-in brake IGBT for quick stops
Complete Specifications
| Model | 22B-D2P3C104 |
| Power | 1HP (0.75kW) |
| Voltage Range | 342-528V AC |
| Current | 2.3A output / 3.2A input |
| Protection | IP66/NEMA 4X (Water & dust proof) |
| Temperature | -10°C to 50°C (14°F to 122°F) |
| Weight | 2.2 kg (4.8 lbs) |
| Safety | Class 10 motor protection |
Expert Questions Answered
1. Can I use this in food processing plants?
Yes! The IP66 rating makes it perfect for washdown areas.
2. What’s the difference between IP66 and NEMA 4X?
IP66 is international standard, NEMA 4X is North American – both offer similar protection.
3. Does it need extra cooling?
No, the sealed enclosure works up to 50°C without fans.
4. Can I mount it upside down?
Yes, the 22B-D2P3C104 can be mounted in any position.
5. Is the keypad waterproof?
Yes, the entire unit meets IP66 standards.
What’s Included
- 22B-D2P3C104 drive unit
- Mounting hardware kit
- Quick start guide
Order With Confidence
12-month warranty on all parts and labor. Ships same day via FedEx, UPS or DHL.
