Description
Allen-Bradley 22D-B8P0N104 PowerFlex Drive – 2HP Industrial Motor Control
Precision meets power: The 22D-B8P0N104 delivers reliable 2HP (8A) motor control with flexible I/O options in a compact panel-mount design.
Top Features
- ⚡ Powerful output: 8A continuous current (2HP)
- ???? Dual control modes: Sensorless vector & V/Hz
- ????️ Advanced protection: Over/under voltage trip protection
- ???? Flexible I/O: 7 digital + 2 analog inputs
- ???? Compact size: Fits tight spaces (3.94 x 9.61 x 6.34 in)
Technical Specifications
- Model: 22D-B8P0N104 (Frame B)
- Input: 200-240V AC 3-phase
- Output: 8A (2HP/1.5kW)
- Mounting: Panel mount (IP20)
- Display: 4-digit with status LEDs
- Temperature: -10°C to 50°C (14°F to 122°F)
- Altitude: Up to 1000m operation
- UPC: 820919654015
What’s Included
- 22D-B8P0N104 drive unit
- Mounting hardware
- Quick start guide
Your Protection
Enjoy 12 months of coverage against manufacturing defects.
Fast Shipping
Reliable delivery via FedEx, UPS or DHL with tracking.
Expert Answers
- Can I use this at high altitudes?
Yes, up to 1000m without derating. - What’s the difference between sensorless and V/Hz modes?
Sensorless offers better torque control at low speeds. - Is the display removable?
No, it’s integrated into the unit. - Can I add an EMC filter later?
Yes, external filters can be added. - What’s the warranty on the display?
Covered under the 12-month warranty.
Compare With Higher-Power Models
- 22D-D024F104 – 7.5HP flange mount version
- 22D-D024H204 – 7.5HP NEMA 4X version
