Allen-Bradley 22D-D010H204 PowerFlex Drive – 5HP Industrial Powerhouse
Compact control for demanding applications: The 22D-D010H204 delivers reliable 5HP (10.5A) motor control with flexible mounting options.
Technical Specifications
- Model: 22D-D010H204 (Frame B)
- Input: 480V AC 3-phase (50-60Hz)
- Output: 10.5A (5HP)
- Mounting: Plate mount (IP20)
- Temperature: 0°C to 40°C (32°F to 104°F)
- Altitude: Up to 1000m operation
- Enclosure: Optional NEMA 4/IP66 available
- Weight: 3.2kg (7lbs)
Package Contents
- 22D-D010H204 drive unit
- Mounting hardware
- Installation manual
Your Assurance
Backed by 12 months of protection against defects.
Fast Shipping Options
Available via FedEx, UPS or DHL with tracking.
Expert Answers
- Can this drive handle 600V input?
No, maximum is 480V AC. - Is DIN rail mounting included?
Yes, both DIN rail and panel options. - What’s the difference between IP20 and NEMA 4?
NEMA 4 offers waterproof protection. - Can I use this for conveyor systems?
Yes, ideal for smart conveyors. - Is programming software included?
No, but parameters can be set manually.
Compare With Similar Models
- 22D-D1P4H204 – Higher capacity 7.5HP version
- 22D-D1P4N104 – Standard enclosure 7.5HP model
