Allen-Bradley 1769-OW16: 16-Channel Relay Output Module
The 1769-OW16 is a 16-point relay output module manufactured by Allen-Bradley for CompactLogix systems. This versatile module operates across both AC and DC voltage ranges, making it ideal for various industrial automation applications.
Technical Specifications
- Brand: Allen-Bradley / Rockwell Automation
- Model: 1769-OW16
- Type: 16-Channel Relay Output Module
- Operating Voltage: 5-265V AC or 5-125V DC
- Output Configuration: 16 Normally Open (Form A) Contacts
- Current Rating: 2.5A per point, 20A module maximum
- Switching Delay: 10 ms (on/off)
- Isolation Groups: 2 groups (8 points each)
- Power Consumption: 4.75 Watts
- Temperature Range: 0 to 60°C
- Wire Compatibility: 22-14 AWG (Solid) or 22-16 AWG (Stranded)
- Controller Compatibility: MicroLogix 1500, CompactLogix systems
Installation Guide
- Install the module in any slot adjacent to your controller unit
- The module requires its own power supply except with MicroLogix 1500 base
- Use appropriate copper wiring (22-14 AWG solid or 22-16 AWG stranded)
- Maintain maximum power supply distance of 8 modules
- Ensure proper grounding and follow all electrical safety standards
Packaging Contents
- One Allen-Bradley 1769-OW16 module
- Installation documentation and user manual
Frequently Asked Questions
- What controllers support the 1769-OW16?
- It works with CompactLogix and MicroLogix 1500 systems
- What is the maximum switching current?
- Each point handles up to 2.5A, with 20A total per module
- Can it control both AC and DC loads?
- Yes, it supports 5-265V AC and 5-125V DC operation
- What is the response time?
- 10 milliseconds for both on and off states
