Schneider Electric BMENOP0300C – Modicon M580 | Communication Module

Description

Modicon M580 Communication Module: High-Performance Industrial Connectivity

The Modicon M580 communication module delivers robust industrial networking for the M580 PAC system. This standard-format module supports multiple Ethernet protocols and operates reliably in harsh conditions.

Core Technical Specifications

• Brand: Schneider Electric
• Model: Modicon M580 (US1PC3418160)
• Physical Interface: 3x Ethernet 10/100BASE-TX ports (RJ45)
• Transmission Medium: Standard Ethernet cable
• Transmission Rates: 10 Mbit/s and 100 Mbit/s
• Communication Services: MMS client/server IEC 61850, GOOSE, Modbus TCP
• Network Features: RSTP support and IP forwarding
• Internal Power Consumption: 1250 mA at 3.3 V DC
• Module Weight: 0.53 lb (0.24 kg)

Environmental Durability & Operating Conditions

• Operating Temperature: 32 to 140 °F (0 to 60 °C)
• Storage Temperature: -40 to 185 °F (-40 to 85 °C)
• Relative Humidity: 0 to 95% (non-condensing)
• Maximum Operating Altitude: 6,561 ft (2,000 m)
• Protective Coating: Conformal coating for extra resilience
• Environmental Resistance: Gas, dust, sand, salt, mold, and fungal spores
• Hazardous Location Certification: Suitable for Class I Division 2 areas

Certifications & Compliance Standards

• Product Certifications: CE, UL, CSA, RCM, EAC, Merchant Navy
• ATEX/IECEx: Approved for use in Zone 2/22
• Key Standards: EN/IEC 61131-2, EN/IEC 61010-2-201, UL 61010-2-201
• Industrial Compliance: IACS E10 and EN/IEC 61850-3 for location G

Packaging & Shipping Information

• Unit Package (PCE): Contains 1 module
• Package 1 Dimensions: 4.57 x 4.37 x 2.17 in (11.6 x 11.1 x 5.5 cm)
• Package 1 Weight: 9.347 oz (265 g)
• Bundle Package (S02): Contains 5 modules
• Package 2 Dimensions: 15.75 x 11.81 x 5.91 in (40 x 30 x 15 cm)
• Package 2 Weight: 3.657 lb (1.659 kg)
• Shipping Carriers: We ship globally via FedEx, UPS, and DHL
• Country of Origin: France (FR)

Frequently Asked Questions (FAQ)

• What protocols does the Modicon M580 module support? It supports Modbus TCP, IEC 61850 MMS, and GOOSE messaging.
• What is the operating temperature range? It operates from 32°F to 140°F (0°C to 60°C).
• Can this module function in hazardous locations? Yes, it holds ATEX/IECEx certifications for Zone 2/22.
• How many Ethernet ports does it have? It provides three 10/100BASE-TX Ethernet ports.
• What is the module’s power consumption? It uses 1250 mA at 3.3 V DC internally.
