Allen-Bradley 1756-ON8: AC Power Output Module
Control AC devices with the reliable 1756-ON8 output module. This versatile module provides 8 AC output points for various applications. It works with 240V AC systems for industrial control. Perfect for motor starters and AC load control.
Need complete AC specifications? Download our detailed guide:
Technical Specifications
Brand & Model: Allen-Bradley 1756-ON8
Type: 8-Point AC Output Module
Voltage Rating: 240V AC
Operating Range: 10-30V AC
Frequency: 50-60 Hz
Current per Point: 2.0A @ 60°C
Total Module Current: 5.0A @ 30°C, 4.0A @ 60°C
Response Time: 9.3ms @ 60Hz, 11ms @ 50Hz
Backplane Power: 5.1V @ 200mA
Power Dissipation: 5.1 Watts maximum
Terminal Blocks: 1756-TBNH, 1756-TBSH
Operating Temp: 0°C to 60°C
Weight: 0.363 kg
Status Indicators: Per-point monitoring
Expert FAQs
Q: What AC voltage does the 1756-ON8 support?
A: It handles 240V AC with an operating range of 10-30V AC.
Q: Can I replace this module without shutting down?
A: Yes, the 1756-ON8 supports hot-swapping without disrupting other system operations.
Q: What frequency does it work with?
A: It operates with both 50Hz and 60Hz power systems.
Q: How many devices can I control?
A: With 8 output points, you can control multiple AC devices simultaneously.
Q: What are the status indicators for?
A: Built-in LEDs provide per-point status monitoring for easy troubleshooting.
