Armored Bently Nevada 330104-01-06-10-01-00 | 3300 XL 8mm M10 Vibration Probe

Description

Product Overview: Armored Metric Vibration Sensor

This Bently Nevada 3300 XL 8mm Probe offers extra physical protection. It features a durable metal armor case. The M10x1 metric thread fits international machinery. This robust sensor is built for demanding industrial environments.

Detailed Product Configuration

Your specific model is 330104-01-06-10-01-00. Here is what each part means:

• Model Base: 330104 (8mm, M10x1, With Armor)
• Configuration Details:


  01 — Unthreaded Length = 10 mm

  06 — Overall Case Length = 60 mm

  10 — Total Cable Length = 1.0 meter

  01 — Connector = ClickLoc with Metal Protector

  00 — Agency Approvals = None

Technical Specifications

• Electrical & Measurement
  • ✓ Probe Resistance: 7.59 Ω ±0.50 Ω (1.0m cable)
  • ✓ Linear Range: 2.0 mm (80 mils)
  • ✓ Sensitivity: 7.87 V/mm (200 mV/mil)
  • ✓ Field Wiring: Max 305 meters with shielded cable
• Mechanical Design
  • ✓ Thread Type: M10 x 1.0 metric
  • ✓ Case Material: Armored Stainless Steel
  • ✓ Tip Material: PPS Plastic
  • ✓ Torque: 11.2 N•m recommended (100 in•lbf)
  • ✓ Max Thread Engagement: 15 mm
• Environmental Ratings
  • ✓ Temperature: -52°C to +177°C operating range
  • ✓ Humidity: Stable in high humidity conditions
  • ✓ Pressure Seal: Viton® O-ring standard
  • ✓ Armor: Extra protection against impact

Key Features & Benefits

• Armor Protection: Metal armor guards against physical damage.
• Connector Protector: Metal shield protects the ClickLoc connector.
• Standard Length: 1.0 meter cable suits most applications.
• Metric Compatibility: M10x1 thread for global equipment.
• Proven Durability: 8mm design and TipLoc molding for long life.

Installation Guide

• Install in M10x1 threaded hole. Ensure clean threads.
• Apply 11.2 N•m torque. Do not exceed 33.9 N•m maximum.
• Set probe gap to about 1.27mm from the target shaft.
• Connect the cable using the protected ClickLoc connector.
• Use proper shielded field wiring for signal integrity.

Typical Applications

• Heavy machinery in mining and mineral processing.
• Pulp and paper mills with high vibration areas.
• Any environment where probes may suffer physical impact.
• Machinery requiring standard metric M10 fittings.

Professional FAQs

What is the benefit of the armored case?

The armor adds a metal sleeve over the probe body. It protects against hits from tools, debris, or during maintenance. It extends probe life in rough environments.

What does connector option ’01’ include?

Option ’01’ includes a miniature coaxial ClickLoc connector PLUS a threaded metal protector. This protector screws over the connector to shield it from damage.

Is this probe suitable for hazardous areas?

No. This model (approval option ’00’) lacks ATEX/IECEx certification. For hazardous areas, you need a model with approval code ’05’. Explore other 3300 XL 8mm Probes with certifications.

Why choose a 60mm case length?

A 60mm case is a common, versatile length. It fits most standard mounting depths for machinery with M10 threads. It’s a good general-purpose choice.

Can the armor be removed or installed later?

No. The armor is a permanent part of the probe case. You must select the armored (330104) or non-armored (330103) model when ordering.

Ordering & Service Details

• Package Contents: 1 x Bently Nevada 330104-01-06-10-01-00 probe.
• Warranty: Full 12-month manufacturer warranty.
• Shipping: Reliable worldwide delivery via FedEx, UPS, DHL.
• Support: Contact us on WhatsApp at +86 158 8020 0923.
