Description
Core Product Details
- Brand: Bently Nevada
- Full Part Number: 330103-07-18-10-02-00
- Product Family: 3300 XL Series
- Item Type: 8mm Diameter Proximity Probe
Understanding Your Model Number
- 330103 – Base Model
- 3300 XL Platform
- 8mm Sensing Tip
- M10 x 1.0 Thread
- Standard Housing
- -07 – Unthreaded Shaft
- Length: 70 mm
- -18 – Body Dimensions
- Overall Case Length: 180 mm
- -10 – Attached Cable
- Length: 1.0 meter (3.3 feet)
- -02 – Termination
- ClickLock Mini-Coaxial Connector
- Standard Cable Type
- -00 – Certifications
- No Special Agency Approvals
Key Technical Parameters
- Sensing Range: 2.0 mm (80 mils) linear
- Optimal Gap: -9 Vdc (~1.27 mm / 50 mils)
- Electrical: DC Resistance: 7.59 Ω ± 0.50 Ω
- Build: PPS Tip, 303/304 SS Case
- Thread: M10x1, Max engagement 15 mm
- Torque (Full Threads): Max 33.9 N•m, Recommend 11.2 N•m
- Torque (First 3 Threads): Max 22.6 N•m, Recommend 7.5 N•m
- Temperature: -52°C to +177°C operation
- Hazardous Area: Compliant for use with proper barriers
Expert Questions & Answers
Q: My model has a 70mm unthreaded section. Why is this length useful?
A: This 70mm section positions the tip correctly in deep mounting holes. It ensures the sensing face reaches the target before threading begins.
Q: The case is 180mm long. How do I install it correctly?
A: Your mounting hole must be deeper than 180mm. This allows the full probe body to seat properly for a stable and accurate measurement.
Q: What is the correct installation torque for this probe?
A: Use a torque wrench. For full thread engagement, tighten to 11.2 N•m (100 in-lbf). Do not exceed 33.9 N•m to avoid damage.
Q: Is this model compatible with all Bently Nevada systems?
A: This 330103 probe works with 3300 XL system monitors. For newer systems, check if you need a 3300 NSv Probes instead.
Q: What if I need this part urgently for a repair?
A: We stock this item. Choose FedEx, UPS, or DHL Express at checkout for fast delivery. Your order includes a 12-month quality warranty.
