Description
Product Description
- Brand: Bently Nevada
- Model: 125760-01 Data Manager I/O Module
- Designed for reliable industrial data acquisition and system integration.
- Supports mixed analog and digital signal processing.
- Built for continuous operation in harsh environments.
- Ethernet-ready for fast and stable data exchange.
- Compact structure simplifies panel installation.
Key Technical Specifications
- Power Supply: 18 to 32 VDC wide input range.
- Analog Inputs: Up to 16 channels for sensor signals.
- Digital Inputs: Up to 16 discrete input points.
- Relay Outputs: Up to 8 programmable relays.
- Communication: 10/100 Mbps Ethernet interface.
- Dimensions: 220 × 180 × 95 mm.
- Weight: Approx. 0.2 kg.
Measurement & Performance Characteristics
- Wide measurement range supports industrial sensors.
- Stable frequency response for monitoring applications.
- High sensitivity ensures accurate signal capture.
- Good linearity improves data consistency.
- Fine resolution enhances diagnostic precision.
- Strong noise immunity reduces signal interference.
Environmental & Reliability Data
- Operating Temperature: -20°C to +60°C.
- Designed for vibration and industrial electrical noise.
- Suitable for long-term continuous operation.
Installation Guide
- Mount securely inside a standard control cabinet.
- Ensure stable DC power before wiring signals.
- Allow airflow for heat dissipation.
- Connect Ethernet for configuration and monitoring.
Commissioning & Maintenance
- Simple setup using standard network tools.
- LED indicators assist quick status checks.
- Modular design eases replacement.
- Minimal routine maintenance required.
Compatibility
- Compatible with Bently Nevada monitoring systems.
- Supports common industrial sensors and switches.
- Integrates with Ethernet-based control networks.
Certifications
- CE compliance.
- UL certified.
- CSA approved.
Typical Applications
- Machinery condition monitoring.
- Industrial automation systems.
- Process data acquisition.
- Predictive maintenance platforms.
Diagnostic Capabilities
- Real-time input status monitoring.
- Early fault detection through signal analysis.
- Supports preventive maintenance strategies.
Package Contents
- 1 × Bently Nevada 125760-01 I/O Module.
- Standard factory packaging.
Warranty & Logistics
- Warranty: 12 months.
- Fast global shipping via FedEx, UPS, or DHL.
FAQ
- Is this module suitable for continuous operation?
- Yes. It is designed for 24/7 industrial use.
- Can it replace older Bently Nevada I/O modules?
- Yes. Check system compatibility before replacement.
- What is a common installation mistake?
- Poor grounding may cause signal noise.
- How to choose the right I/O module?
- Match channel count, voltage, and network needs.
