Description
Precise Pressure Measurement for Demanding Engines
The Bently Nevada 165855-16-CN delivers accurate cylinder pressure data. This robust transducer handles extreme conditions inside engines. It is perfect for performance testing and continuous monitoring. Get reliable data to optimize engine operation and safety.
Core Benefits for Your Application
- Extreme Pressure Rating: Measures up to 5000 PSIA for large engines.
- High-Speed Response: Captures fast pressure changes accurately.
- Armored Protection: Built-in armor withstands harsh cylinder environments.
- Wide Temperature Range: Operates reliably in very hot or cold conditions.
- Low Power Use: Simple to integrate with standard power supplies.
Complete Technical Data
- Brand & Model: Bently Nevada 165855-16-CN
- Product Type: Cylinder Pressure Transducer
- Pressure Range: 0 to 345 bar (0 to 5,000 PSIA)
- Power Requirement: 18 to 30 VDC
- Current Draw: Less than 15 mA
- Output Signal: 10 VDC full scale
- Zero Signal: 0.5 VDC
- Frequency Response: 0 to 5500 Hz
- Accuracy: ±1 dB across frequency range
- Linearity: Excellent across full pressure scale
- Operating Temp: -40°C to +85°C
- Compensated Temp: -40°C to +85°C
- Proof Pressure: 1.5 x Full Scale (517 bar / 7,500 PSIA)
- Burst Pressure: 3 x Full Scale (1035 bar / 15,000 PSIA)
- Connection: Electrical connector and pressure port
- Housing: Armored construction for durability
Order & Delivery Information
- This is a genuine 165855-16-CN transducer.
- Includes standard electrical connector.
- Protected by a 12-month warranty.
- Fast shipping via FedEx, UPS, or DHL available.
- Global delivery with full tracking service.
Simple Guide to Purchasing
Identify your engine’s maximum cylinder pressure. The 165855-16-CN covers up to 345 bar. Ensure you have a compatible 24VDC power source and data acquisition system. Order for accurate combustion analysis and protection.
Expert Answers to Your Questions
What engines is this transducer designed for?
It is ideal for large diesel and gas engines. This includes marine propulsion, power generation, and locomotive engines.
Why is the frequency response important?
A high 5500 Hz response captures rapid combustion events. This is critical for accurate performance analysis and knock detection.
Can it be used for continuous monitoring?
Yes. Its rugged design allows permanent installation. It provides real-time pressure data for engine protection systems.
What is a key installation tip from field service?
Always use a proper mounting adapter. Ensure the pressure port is clean and free of debris before installation to prevent damage.
How do I interpret the output voltage?
0.5V equals zero pressure. 10V equals 5000 PSIA full scale. Your monitoring system scales this signal to engineering units.
