Bently Nevada 170180-03-00 FieldMonitor PLC Rack Module Smart Monitoring

Description

Product Overview

• Brand
  • Bently Nevada
• Model
  • 170180-03-00
• Series
  • FieldMonitor
• Category
  • PLC Module and Rack Unit
• Built for reliable vibration data handling.
• Supports Velomitor vibration transducers.

Key Selling Points

• Compact rack saves cabinet space.
• Fast response improves machine protection.
• Stable performance in harsh plants.
• Easy link to control systems.

Electrical Power and Inputs

• Power Section
  • Nominal supply: 24 V DC
  • Allowed range: 24 V ±10%
  • Power draw: Less than 12 W
• Input Channels
  • Total channels: 4 independent inputs
  • Input signal range: 0 to 100 mV
  • Max signal level: 10 Vpp
  • Input impedance: Above 100 kΩ

Signal Processing and Outputs

• Processing Core
  • Advanced digital signal processing engine
  • High noise rejection design
  • Sampling rate up to 10 kHz
• Output Options
  • Analog outputs: 4–20 mA or 0–10 V
  • Digital outputs for alarms and status
  • Resolution: 16-bit
  • Output update time: Under 5 ms

Environmental and Mechanical

• Operating Conditions
  • Temperature range: -40°C to +85°C
  • Humidity: 5% to 95% non-condensing
• Physical Design
  • Size: 5.5 x 3.5 x 2.0 inches
  • Weight: Approx. 0.9 kg
  • DIN rail or panel mounting
• Protection Level
  • Environmental rating: IP20
  • For control cabinet use

Safety and Protection

• Overvoltage protection on all inputs.
• Overcurrent protection for outputs.
• Thermal shutdown for internal safety.
• Response time: 5 ms.

Communication and Integration

• Protocols
  • Modbus RTU
  • Modbus TCP/IP
• System Fit
  • Fully compatible with FieldMonitor systems
  • Easy PLC and DCS integration
• Data Handling
  • Non-volatile memory for settings
  • Retains data during power loss

Certifications

• UL listed
• CE compliant
• Designed for industrial standards

Packaging and Warranty

• One PLC module and rack unit.
• Quick reference guide.
• Warranty: 12 months.
• Delivery via FedEx, UPS, or DHL.

Typical Applications

• Machine vibration monitoring.
• Critical asset protection.
• Plant condition systems.
• Energy and process industries.

FAQ

• • Can this module run without a PLC
  • Yes, it works as a standalone monitor.
  • Is this unit suitable for remote sites
  • Yes, it supports long-term stable operation.
  • How do I select the right FieldMonitor rack
