Description
Complete Housing Kit for 8mm Probes
Introducing the Bently Nevada 31000-28-10-00-015-03-02. This is a full protective kit for your 8 mm vibration probe. It includes the housing body, a 1-meter cable, and all necessary installation fittings. Ready for quick and secure mounting in tough locations.
Part Number Decoder
Product Family: 31000 Housing
Feature Selection (Suffix by Suffix):
- 28 → Accepts: 3300 XL 8 mm Probe
- 10 → Cable at Housing: 1.0 meter pre-cut length
- 00 → Standoff: Not Included (Direct Mount)
- 015 → Probe Depth: 1.5 inches into housing
- 03 → Fittings Kit: Complete with seals & reducer
- 02 → Mount: 3/4-14 NPT Thread
Why This Housing Kit Stands Out
- All-In-One Package: Comes with plugs, reducer, and cable seals. Saves time sourcing parts separately.
- Integrated Cable: Has a pre-cut 1-meter cable at the housing exit. Makes connection neat and professional.
- Hazardous Area Certified: Conductive plastic body prevents static. Safe for use in classified locations.
- Weatherproof Design: Rated NEMA 4X / IP66. Protects against hose-down water and dust.
- Trusted Solution: A core component of the 31000 Proximity Probe Housing Assemblies series.
Detailed Specifications
- Core Identification
- Brand: Bently Nevada
- Model: 31000-28-10-00-015-03-02
- Function: Probe Protective Enclosure Kit
- Included Components
- Housing Body (Conductive PPS Plastic)
- 1.0 Meter Probe Cable Section
- Two Plugs, One 3/4-14 NPT Fitting
- Stainless Steel Reducer (3/4″ to 1/2″ NPT)
- Cable Seal Grip with 3 Grommet Sizes
- All Stainless Steel Hardware
- Performance & Ratings
- Enclosure: NEMA 4X, IP66 (Watertight)
- Temperature: -51°C to +105°C
- Impact Rated: Certified for high-energy strikes
- Hazardous Area: Complies with CENELEC EN50014
- Retaining Nut Torque: 29.4 N·m
- Total Weight: Approx. 1.2 kg
Simple Installation Steps
- Mount the housing using the 3/4-14 NPT thread.
- Insert your 8 mm probe to the 1.5-inch depth mark.
- Secure the probe using the retaining nut (29.4 N·m torque).
- Pass your main probe cable through the correct seal grommet.
- Tighten the cable seal grip to form a watertight seal.
- Use the provided plugs to seal any unused ports.
Ordering & Support Info
- Warranty Coverage: Backed by a full 12-month manufacturer’s warranty.
- Fast Delivery: Stock items ship via FedEx, UPS, or DHL.
- Perfect For: Protecting Bently Nevada 3300 XL 8 mm probes.
- Technical Help: Get instant support on WhatsApp: +86 158 8020 0923.
Professional FAQs
About the Kit Contents
- Q: What is the “cable seal grip” used for?
- A: It is a compression fitting. It tightly seals around your probe’s main cable where it enters the housing. This keeps water and dust from following the cable inside.
- Q: Why does the kit include a pipe reducer?
- A: The housing has a 3/4-inch NPT port. The reducer allows you to connect it to a common 1/2-inch NPT pipe or conduit if needed, offering installation flexibility.
Application & Selection
- Q: Should I choose this kit or a housing without fittings?
- A> Choose this -03- fittings kit if you are doing a new installation. It has all the common parts you need. Choose a -00- (no fittings) version only if you are replacing an existing housing and will reuse old fittings.
- Q: Can the pre-attached 1-meter cable be extended?
- A> Yes. The 1-meter cable exiting the housing has a standard Bently Nevada connector. You can connect it to a longer extension cable to reach your monitor.
Practical Experience Tip
- Q: What’s a common mistake when using the seal grommets?
- A> Using the wrong size grommet for the cable diameter. This can cause a poor seal. Always match the grommet to your cable’s outer jacket size. Test the seal by pulling gently on the cable after tightening.
