Bently Nevada 3300 NSv Probe 330904-08-15-05-12-00 Buy Now

Description

Bently Nevada 3300 NSv Proximity Probe – New & Original with 12-Month Warranty

Complete Specifications

• Brand: Bently Nevada
• Full Model: 330904-08-15-05-12-00
• Suffix Details:
  • 330904: NSv Probe, M8X1 thread with armor
  • -08: 80mm unthreaded length
  • -15: 150mm overall case length
  • -05: 0.5m cable (20″)
  • -12: Miniature coaxial ClickLoc connector, FluidLoc cable
  • -00: Agency approval not required

Technical Performance

• Electrical:
  • Probe resistance: 4.0Ω ±0.5Ω
  • Cable capacitance: 69.9 pF/m
  • Frequency response: 0-10kHz (±3dB)
• Measurement:
  • Linear range: 0.25-1.75mm (10-70 mils)
  • Scale factor: 7.87 V/mm (200 mV/mil)
  • Linearity: ±0.06mm (±2.3 mils)
• Durability:
  • Operating temp: -52°C to +177°C (-62°F to +351°F)
  • Stainless steel case with PPS tip
  • Minimum bend radius: 25.4mm (1″)

Installation Guide

• Recommended gap: 1.0mm (40 mils)
• Mounting torque: 5.1 N•m (45 in•lb)
• M8x1 thread with 12mm engagement
• Armored cable with ClickLoc connector

Package & Support

• Factory new in original packaging
• 12-month warranty
• Global shipping: FedEx, UPS, DHL
• Download installation manual

FAQ

• Q: Minimum target size?
  A: 8.9mm diameter (13mm recommended)
• Q: Pressure rating?
  A: Viton O-ring seal (not pressure tested)
• Q: Cable options?
  A: 0.5/1/5/7m FEP-insulated coaxial
• Q: Chemical resistance?
  A: Superior to 3300 RAM probes
