Bently Nevada 3300 NSv Proximity Probe – High-Performance Vibration Monitoring
New & original 3300 NSv proximity probe with 12-month warranty. Designed for precision vibration measurement in harsh industrial environments. Features M8x1 threading, armored cable, and superior chemical resistance.
Technical Specifications
Brand: Bently Nevada
Model: 3300 NSv Proximity Probe
Full Part Number: 330904-08-15-05-01-00
Electrical Characteristics
- Probe resistance: 4.0Ω ±0.5Ω (0.5m cable)
- Cable capacitance: 69.9 pF/m typical
- Incremental Scale Factor: 7.87 V/mm (±12.5%)
Mechanical Specifications
- Linear range: 0.25-1.75mm (10-70 mils)
- Recommended gap: 1.0mm (40 mils)
- Frequency response: 0-10 kHz (±3dB)
Environmental Ratings
- Temperature range: -52°C to +177°C
- Pressure seal: Viton O-ring design
- Minimum bend radius: 25.4mm
Complete Suffix Breakdown
330904 Base model (3300 NSv Probe) -08 Unthreaded length: 80mm -15 Overall case length: 150mm -05 Cable length: 0.5m (20") -01 Connector: Miniature coaxial ClickLoc -00 No agency approvals
Installation & Maintenance
- Torque specification: 5.1 N•m (45 in•lb) recommended
- Thread engagement: 12mm max for M8x1
- Use shielded triad cable for field wiring (max 305m)
Compatibility
Fully compatible with:
- Bently Nevada 3300 RAM probe systems
- 3300 XL NSv Proximitor Sensors
What’s Included
- 3300 NSv Probe with armor
- ClickLoc connector protector
- Factory packaging
- 12-month warranty card
Shipping & Support
Fast worldwide delivery via FedEx, UPS, or DHL. Technical support available for installation and troubleshooting.
Need More Details?
Download the complete product manual for installation guides and technical drawings:
FAQ
Q: What’s the difference between NSv and RAM probes?
A: NSv offers better chemical resistance and improved side-view characteristics.
Q: Can I use this on shafts smaller than 13mm?
A: Yes, but scale factor may change. Reduce probe gap to minimize effect.
