Description
Bently Nevada 330903-00-05-70-11-00 Proximity Sensor
Key Features
New factory-sealed proximity probe with 50mm case length and special FluidLoc cable. Perfect for wet or oily environments. Includes 12-month warranty.
Model Number Explained
Each part of the model number tells a story:
- 330903: Base model (M8X1 thread)
- 00: Unthreaded section (0 mm)
- 05: Case length (50 mm)
- 70: Cable length (7.0 meters)
- 11: FluidLoc cable with ClickLoc connector
- 00: No special approvals needed
Technical Details
| Manufacturer: | Bently Nevada |
| Cable Type: | FluidLoc (fluid-resistant) |
| Probe Tip: | PPS plastic |
| Case Material: | 304 Stainless Steel |
| Electrical Specs: | 5.9Ω resistance ±0.9Ω |
| Temperature Range: | -62°F to +351°F |
| Max Wiring Distance: | 1000 feet |
Installation Guide
- Best gap: 1.0 mm (40 mils)
- Max torque: 7.3 N•m (65 in•lb)
- Min bend radius: 1.0 inch
- Thread engagement: Max 12mm
Shipping & Support
- Original factory packaging
- 12-month manufacturer warranty
- Worldwide delivery: FedEx, UPS, DHL
- No certificates included
Important Notes
- FluidLoc cable resists oils and chemicals
- 50mm case for deeper installations
- Not pressure tested by default
- Use Viton O-ring for sealing
Common Questions
Q: What makes FluidLoc cable special?
A: It has extra protection against oils and chemicals that damage standard cables.
Q: When would I need the 50mm case?
A: When mounting in deeper holes or needing more thread engagement.
Q: Can I replace old RAM probes with this?
A: Yes, it works with all 3300 RAM compatible systems.
Q: What’s the cable length exactly?
A: 7.0 meters (23.0 feet) from probe tip to connector.
