Bently Nevada 3300 NSv Proximity Probe | 330904-08-10-10-01-00

Description

Bently Nevada 3300 NSv Proximity Probe: Precision Vibration Monitoring

New OEM 330904-08-10-10-01-00 proximity sensor in factory packaging. Features enhanced chemical resistance and backward compatibility. Includes 12-month manufacturer warranty.

Complete Suffix Breakdown

• Base Model: 330904 (NSv Probe, M8X1 thread, armored)
• -08: 80 mm unthreaded length
• -10: 100 mm case length
• -10: 1.0 meter cable (39 in)
• -01: ClickLoc connector + protector
• -00: No agency approval

Technical Specifications

• Brand: Bently Nevada
• Model: 3300 NSv Proximity Probe
• Linear Range: 1.5 mm (0.25-1.75 mm)
• Sensitivity: 7.87 V/mm ±20%
• Linearity: <±0.06 mm deviation
• Electrical: 4.2Ω probe resistance, 0.220Ω/m center conductor
• Temp Range: -52°C to +177°C
• Housing: AISI 304 stainless steel
• Tip Material: Chemical-resistant PPS

Installation Guide

• Gap Setting: 1.0 mm (40 mils)
• Torque: 5.1 N•m (finger tight + 1/4 turn)
• Min Bend Radius: 25.4 mm
• Max Thread Engagement: 12 mm

Packaging & Support

• 12-month warranty
• New in factory-sealed packaging
• Global shipping: FedEx/UPS/DHL
• Supporting documents:
  • Installation guide

Diagnostic Capabilities

• 0-10 kHz frequency response
• Detects sub-millimeter vibration changes
• Compatible with 3300 XL NSv monitors

FAQ

• Q: Compatible with 3300 RAM systems?
  A: Yes, fully interchangeable
• Q: Minimum target size?
  A: 8.9 mm diameter (13 mm recommended)
• Q: Pressure testing available?
  A: Contact for custom testing

Get Full Documentation

Download complete technical manual:

• Installation procedures
• Calibration guidelines
• Troubleshooting checklist
