Bently Nevada 3300 NSv Proximity Probe | 330904-08-10-50-02-00

Description

Bently Nevada 3300 NSv Probe 330904-08-10-50-02-00 – 5m Industrial Sensor

Model Configuration

• Full Part: 330904-08-10-50-02-00
• Configuration Details:
  • Base model: 330904 (M8X1 armored)
  • Unthreaded length: 80mm
  • Case length: 100mm
  • Cable length: 5.0 meters
  • Connector: Standard ClickLoc
  • Approvals: Not required

Technical Specifications

• Electrical:
  • Probe resistance: 5.3Ω ±0.7Ω
  • Cable capacitance: 69.9 pF/m
  • Frequency response: 0-10kHz (±3dB)
• Performance:
  • Measurement range: 0.25-1.75mm
  • Scale factor: 7.87 V/mm
  • Linearity error: ±0.06mm
• Construction:
  • Case: 304 stainless steel
  • Tip: PPS material
  • Seal: Viton O-ring

Installation Notes

• Optimal gap: 1.0mm (40 mils)
• Max torque: 5.1 N•m (45 in•lb)
• Min bend radius: 25.4mm (1 inch)
• Thread engagement: 12mm max

Order Information

• Condition: New in factory packaging
• Warranty: 12 months
• Shipping: FedEx, UPS, DHL worldwide
• Download product manual here

Technical FAQ

• Q: Cable length impact on signal?
  A: Minimal effect with proper field wiring
• Q: Chemical resistance level?
  A: Higher than 3300 RAM probes
• Q: Minimum operating temperature?
  A: -52°C (-62°F)
• Q: Pressure testing available?
  A: Custom service only
• Q: Replacement for older models?
  A: Fully compatible with 3300 RAM
