Bently Nevada – 3300 NSv Proximity Probe 330904-08-10-70-02-05

Description

Bently Nevada 330904-08-10-70-02-05 3300 NSv Proximity Probe – Industrial Precision Sensor

???? Model Breakdown

• Base Model: 330904
  • Thread Type: M8X1 with Armor
• Length Options:
  • -08: 8mm Unthreaded Length
  • -10: 100mm Case Length
  • -70: 7.0m Cable (23ft)
• Connection Options:
  • -02: ClickLoc Mini-Coaxial
  • -05: Multi-Certified Safety

⚙️ Key Technical Specs

• Probe Resistance: 5.9Ω ±0.9Ω
• Frequency Range: 0-10kHz (±3dB)
• Linear Detection: 0.25-1.75mm
• Temp Range: -52°C to +177°C
• Cable Capacitance: 69.9 pF/m
• Min Target Size: 8.9mm Ø
• Torque Limit: 0.56 N•m
• Bend Radius: 25.4mm Min

❓ Expert FAQs

• Q: What’s the max RPM supported?
  A: Designed for 50,000+ RPM systems
• Q: Compatible with existing Bently systems?
  A: Fully backward compatible with 3300 XL monitors
• Q: Chemical resistance rating?
  A: Resists oils, coolants and industrial solvents
• Q: Installation torque specification?
  A: Finger-tight + 1/4 turn (max 0.56 N•m)
• Q: Pressure sealing capability?
  A: Viton O-ring seals (contact for pressure tests)
